1 panel color: iron black
2 Power input conditions (single-phase 3-wire): AC90-260V 50-60HZ two-phase (three lines: zero,
fire, ground)
3 channel number: 8-way universal socket relay controlled and 1 channel universal socket direct
output
4 Relay controlled output can withstand single channel power / total power (reactive power):
5000W/8000W maximum withstand reactive power
5 output power socket specifications: flame retardant ABS material, can withstand up to 13A current,
brass material, standard universal socket
6 Features: 1. Sequence is turned on in reverse order. 2. PASS button can be turned on at the same
time. 3. Accurate voltage display
7 Inter-switch time/timing time: 1 second
8 output relay contact current: 30A 277VAC
9 Board specifications: double-sided fiberboard, main power supply line double thickening and
thickening
10 Power supply specification: Built-in switching power supply for global voltage AC90-260V 50-
60HZ
11 Main cable specification: 3*4 square cable, total length is 1.0 m (no power input plug)
12 Opening type: square ship type switch
13 function display voltage display table type: red digital tube display voltmeter
14 stacking machine cascade function: none
15 Power Purification Function (EMI Professional Grid Filter): None (optional with separate or each
filter)
16 body size: length 480MM * width 185MM * height 46MM (non-standard 1U)
17 single package size: length 555MM * width 255MM * height 85MM (US beef carton) gross weight:
2.7KG
18 The whole weight and outer package size: 1 piece 5 sets with a total of 14.5KG, outer package
size: length 445 * width 270 * height 570mm
